Weichai Marine Propulsion Engine of 14V32/40 and spare parts

General Information of Weichai 14V32/40 Marine Propulsion Engine
Engine Model 14V32/40
Engine Type 14 Cylinders in Line
Displacement 450.38L
Bore*Stroke(mm) 320*400
Net Weight 68T.
Overall Diemension(L*H*W*H) 7545mm*3140mm*4100mm*3230mm
Rotation direction of crankshaft(seen from the free end) Clockwise
Start mode Air motor
Technical Specification of Weichai 14V32/40 Marine Propulsion Engine
Marine Certification CCS
Aspiration Turbocharged and intercooled
Governor Mechanical
Electrical System(Starter Motor/Alternator) 12V/24V
Cooling Mode high and low tempreture fresh water binary
Performance Data of Weichai 14V32/40 Marine Propulsion Engine
Rated Power/Speed 7000kW/750rpm
Compression ratio 15.2:1
Min. fuel oil consumption 182g/Kw.h
Fuel consumption @rated power 185/Kw.h
As optional of  Weichai 14V32/40 Marine Propulsion Engine
Control Panel As optional
Marine Gearbox As optional of Advance or Fada

Notes: H* is the hoisting height benchmarked at the center of the bent axle.

Curves shown above represent gross engine performance capabilities obtained and corrected in accordance with GB/T18297.
