Weichai Marine Propulsion Engine  X6170ZC-02A and spare parts

General Information of Weichai X6170ZC-02A Marine Propulsion Engine
Engine Model X6170ZC-02A
Engine Type 6 Cylinders in Line
Displacement 27.24 L
Bore*Stroke(mm) 170 * 200
Net Weight (with flywleel & alternator) 3100±50Kg
Overall Diemension(L*W*H) 2432mm*1219mm*1816mm
Rotation direction of crankshaft  Counter Clockwise
Start mode Electric start
Technical Specification of Weichai X6170ZC-02A Marine Propulsion Engine
Marine Certification CCS
Aspiration Turbocharged and intercooled
Governor Mechanical
Electrical System(Starter Motor/Alternator) 12V/24V
Engine Cooling System Sea and fresh water duel-circulation cooling system
Performance Data of Weichai X6170ZC-02A Marine Propulsion Engine
Rated Power/Speed 280kW/1000rpm
Compression ratio 15.1:1
Fuel consumption @ rated power ≤205g/Kw.h
Min. fuel oil consumption 197g/Kw.h
Lub oil and fuel consumption ratio ≤0.89%
As optional of  Weichai X6170ZC-02A Marine Propulsion Engine
Control Panel As optional
Marine Gearbox As optional of Advance or Fada
